200 gallon Union Process Attritor, Jacketed, XP
Category: Attritor
Product ID: 5033
Specifications
- » One (1) used 200 gallon Union Process Attritor
- » Type: B
- » Size: 200S
- » Serial number: 3621
- » Stainless steel jacketed tank
- » 45" diameter x 45" deep
- » 8" diameter discharge screen, tapers to a 2" ball valve
- » 40/10 HP 2-speed motor, belt driven to gear reducer
- » Final shaft RPM is 250 and 60
- » Includes belt guard
- » 3 phase, 440 voltage only
- » Hand crank for tilting tank
- » Shaft and arms are in good condition
- » Removable split top tank cover
- » 3.5" shaft diameter, arms are 1.5" diameter
- » Tank is clean and ready for mixing
- » Includes start/stop buttons and Size 3 single speed motor starter
- » Equipped with Amp and hour meter
- » Currently set for slow speed
- » Overall Dimensions: 89" L - R, 62" F-B, 9' 4" tall
- » Weight: 6900
- » Test ran both speeds, video available
